Three-in-One Handheld Laser Machine Up To 3000w For Welding And 2000w For Cleaning

Name: Three-in-One Handheld Laser Machine Up To 3000w For Welding And 2000w For Cleaning
Brand: Shenzhen Hanwei Laser Equipment Co., Ltd.
SKU: HW-20-60150
Price: 1.00 USD
Availability: InStock

Basic Properties

Place of Origin: Shenzhen. China

Brand Name: HanWei

Certification: CE

Model Number: HW-20-60150

Trading Properties

Minimum Order Quantity: 1 Set

Price: USD / Set

Payment Terms: T/T

Supply Ability: 2000 Sets / year

Stainless Steel Laser Welding Machine

3-in-1 Laser Welding Machine

Aluminium Alloy Laser Welding Machine

Specifications

Laser Power:	Up To 3000w For Welding And 2000w For Cleaning	Handheld Laser Gun Materials:	Aluminium Alloy And Stainless Steel
Handheld Laser Gun Weight:	0.7 Kg	Welding Laser Beam Size:	0-5mm Adjustable
Welding Materials:	Steel / Stainless Steel / Aluminium	Cleaning Laser Beam Size:	0-50mm Adjustable
Wire Feeding Device:	Standard Type : 0.8&1.0&1.2&1.6mm Wire	Double Route Wire Feeder:	Option ( Same Time Double Route Feeding )
High Light:	3000w Welding Handheld Laser Machine , 2000w Cleaning Handheld Laser Machine , Three-in-One Handheld Laser Machine

Product Description

Three-in-One Handheld Laser Machine Up to 3000W for Welding

Three-in-One Handheld Laser Machine Description:

The Three-in-One Handheld Laser Machine represents a significant breakthrough in portable multi-functional equipment. Driven by a single, high-powered motor, this device combines three essential functions: welding, cutting, and cleaning, all housed within a compact and ergonomic handheld shell.

During the welding procedure, it precisely adjusts the electrical current and voltage to generate a stable arc, enabling strong and accurate welds on various steel, stainless steel, and aluminum substances. When it comes to cutting operations, a focused high-intensity beam penetrates different material thicknesses with adjustable speed and depth, ensuring smooth and efficient incisions. In the cleaning function, it intakes cleaning agents or water and transforms them into a powerful adjustable high-pressure stream through a flexible nozzle, effectively removing rust, grease, and contaminants. This machine is highly versatile and suitable for multiple scenarios such as workshops, construction sites, and industrial maintenance, exhibiting outstanding performance in all three core functions.

Three-in-One Handheld Laser Machine Up To 3000w For Welding And 2000w For Cleaning 0

Three-in-One Handheld Laser Machine Features:

Product Name: Three-in-One Handheld Laser Machine
Laser Power: Up to 3000W for Welding and 2000W for Cleaning
Handheld Laser Gun Weight: 0.7kg
Welding Laser Beam Size: 0-5mm Adjustable
Cleaning Laser Beam Size: 0-50mm Adjustable
Laser Head Connection: QBH
Laser Beam Form: Line “一”
Standard Focus length: 60 & 150mm standard Focus length adjustable
Welding Materials: Steel / Stainless Steel / Aluminum
Welding Parameter Save: 30 kinds of different welding parameter save

An ideal choice for metal fabrication, machine restoration and surface treatment in workshops and factories, the Three-in-One Handheld Laser Machine. It has 3000W for welding and 2000W for cleaning, allowing it to weld steel, stainless steel and aluminium. The laser beam features a linear shape and is connected using QBH, requiring Argon or Nitrogen gas. With an adjustable standard focal length from 60 to 150mm, the 0.7kg handheld laser unit offers adjustable laser beam sizes. In addition, it offers adjustable laser beam sizes for welding and cutting. The welding beam size can be adjusted from 0 to 5mm and the cleaning beam size from 0 to 50mm.

Three-in-One Handheld Laser Machine Technical Parameters:

Product Name	Three-in-One Handheld Laser Machine
Laser Power	Up to 3000W for welding and 2000W for cleaning
Handheld Laser Gun Weight	0.7 KG
Standard Focus length	60 and 150mm standard Focus length adjustable
Fiber Connector	QBH
Cleaning Beam Form	Line " 一 "
Adopt Laser Source	1064~1080nm Fiber laser source
Welding Laser Beam Size	0-5mm Adjustable
Cleaning Laser Beam Size	0-50mm Adjustable
Wire Feeding Device	Standard type : 0.8&1.0&1.2&1.6mm wire
Double Route Wire Feeder	Option (Same time double route feeding)
Welding Parameter Save	30 kinds of different welding parameter save

Three-in-One Handheld Laser Machine Application Advantages:

The HanWei HW-20-60150 Three-in-One Handheld Oscillation Tri-functional Machine demonstrates outstanding application advantages. Its highly convenient portability is a result of its compact and lightweight design, making it suitable for restricted areas and mobile operations. This enhances operational flexibility without the need for complex equipment or a large number of personnel.

This apparatus combines welding, cutting, and cleaning functions. In the welding mode, with a power of 2000W, it is capable of welding steel, stainless steel, and aluminum. The welding beam, which can be adjusted within the 0 - 5mm range, can meet various welding demands. For the cutting function, the laser beam can cut through materials with adjustable cutting speed and depth. In the cleaning function, the 0 - 50mm adjustable beam is effective in cleaning a variety of surfaces and is applicable in automotive, household, and industrial equipment cleaning.

It is energy-saving and cost-effective. The single-motor design saves energy, simplifies work procedures, reduces both time and energy consumption. Its simple structure leads to decreases in manufacturing and maintenance costs. It is also user-friendly, as it requires no specialized training, is accessible to a broad range of users, and helps to minimize errors and training-related expenses.

Three-in-One Handheld Laser Machine Packing:

One Handheld Laser Head
One Touch Screen Monitor
One Controller
A set of Connection Cables and Line
One 15v Power Supply
Two Protective Lens
One Safety Switch Clip
One Focus Lens for cleaning
One Wire feeding device
Seven kinds of nozzles
One User Manual

Three-in-One Handheld Laser Machine Up To 3000w For Welding And 2000w For Cleaning 1

Shen Zhen HanWei Laser Enterprise and Feature:

Shenzhen Hanwei Laser Equipment Co., Ltd. is committed to providing all integrators around the world with excellent welding technology. As a national high-tech and specialized new enterprise, it focuses on the research, development, production, and marketing of the comprehensive industrial chain covering welding lasers, laser control systems, laser optical systems, and laser welding processes. The company's product range includes nine major series of laser welding machines, such as AMB Spot Ring Spot Welding Machine, Blue Light Welding Machine, and their corresponding supporting products.

Hanwei Laser adheres to the business concept of "taking R&D as the core, technology as the guarantee, and service as the support" to serve B-end customers. It has a professional team with profound knowledge and experience in laser welding and related fields. The products are widely used in various industries such as new energy batteries, automotive, electronics, and household appliances, showing unique welding capabilities. Remarkably, the company has made significant technological breakthroughs. The AMB Spot Ring Spot + Blue Light Composite Swing Welding Machine is a global pioneer, solving the problems in welding highly reflective materials. Other models like the AMB Spot Ring Spot + Semiconductor Composite Welding Machine and the Semiconductor + Single Lamp Single Rod 600W Composite Laser Welding Machine have also effectively addressed specific welding difficulties in the power battery field.
