Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes: Welding / Cutting / Cleaning

Basic Properties
Place of Origin: Shenzhen. China
Brand Name: HanWei
Certification: CE
Model Number: HW-20-60150
Trading Properties
Minimum Order Quantity: 1 Set
Price: USD / Set
Payment Terms: T/T
Supply Ability: 2000 Sets / year
Tags

Stainless Steel Laser Welding Machine

3-in-1 Laser Welding Machine

Aluminium Alloy Laser Welding Machine
Specifications
Handheld Laser Gun Materials: Aluminium Alloy & Stainless Steel Laser Power: Up To 3000W For Welding And 2000W For Cleaning
Handheld Laser Gun Weight: 0.7 Kg Welding Materials: Steel / Stainless Steel / Aluminium
Welding Laser Beam Size: 0-5mm Adjustable Cleaning Laser Beam Size: 0-50mm Adjustable
Welding parameter storage: 30 Kinds Of Different Welding Parameter Save Wire Feeding Device: Standard Type : 0.8&1.0&1.2&1.6mm Wire
Double Route Wire Feeder: Option ( Same Time Double Route Feeding )
High Light:

3 Modes Handheld Laser Welding Machine

,

Powerful Handheld Laser Welding Machine

,

3-in-1 Handheld Laser Welding Machine
Product Description

Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes : Welding / Cutting / Cleaning





Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes : Welding / Cutting / Cleaning Description:



The Handheld 3 - in - 1 Device ushers in a revolutionary advancement in the realm of portable multi - functional tools. Driven by a single yet powerful motor, this equipment ingeniously combines three essential functions: welding, cutting, and cleaning, all housed within an ergonomic and user - friendly handheld casing.

During the welding process, it meticulously controls the electrical current and voltage to generate a stable arc, enabling firm and accurate connections on various steel, stainless steel, and aluminum materials. For cutting tasks, a focused high - intensity beam penetrates materials of different thicknesses at adjustable speeds and depths, ensuring clean and efficient cuts. As for the cleaning function, it draws in cleaning agents or water and transforms them into a powerful adjustable high - pressure spray through a flexible nozzle, effectively removing rust, grease, and impurities. This apparatus demonstrates exceptional adaptability and is suitable for a wide range of situations, such as workshops, construction sites, and industrial maintenance, providing excellent performance in all three core functions.




Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes : Welding / Cutting / Cleaning Features:

  • Product Name: Fiber Laser 3-in-1 Machine
  • Handheld Laser Gun Weight: 0.7kg
  • Laser Power: Up to 3000W for welding and 2000W for cleaning
  • Welding Laser Beam Size: 0-5mm Adjustable
  • Cleaning Laser Beam Size: 0-50mm Adjustable
  • Laser Head Connection: QBH
  • Laser Beam Form: Line “一”
  • Standard Focus length: 60 and 150mm standard Focus length adjustable
  • Welding Materials: Steel / Stainless Steel / Aluminum
  • Gas: Argon / Nitrogen
  • Cooling method: Water Cooling



The Handheld All - in - One Apparatus stands out as a top - notch choice for metal processing, machinery renovation, and surface treatment tasks in workshops and industrial plants. It operates with a peak power of 3000W for welding operations and 2000W for cleaning functions, enabling it to effectively deal with steel, stainless steel, and aluminum materials. The laser beam assumes a linear shape and is connected through a QBH connection, necessitating argon or nitrogen gas for proper functioning.
This handheld laser device, weighing merely 0.7 kilograms, is fitted with an adjustable standard focal length that spans from 60 to 150mm. Furthermore, it offers adjustable laser beam widths for both welding and cutting processes. More precisely, the welding beam width can be adjusted within the 0 - 5mm range, while the cleaning beam width can be modified from 0 to 50mm. This machine employs a Water Cooling system to ensure efficient heat dissipation during operation. As a result, it can maintain stable performance and have an extended service life.


Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes : Welding / Cutting / Cleaning Technical Parameters:



Product Name

Handheld 3-in-1 Laser Welding Machine

Laser Power

Up to 3000W for welding and 2000W for cleaning

Handheld Laser Gun Weight

0.7 KG

Fiber Connector

QBH

Welding Laser Beam Size

0-5mm Adjustable
Cleaning Laser Beam Size 0-50mm Adjustable
Cleaning Beam Form Line " 一 "
Adopt Laser Source 1064~1080nm Fiber laser source

Wire Feeding Device

Standard type : 0.8&1.0&1.2&1.6mm wire

Double Route Wire Feeder

Option (Same time double route feeding)

Standard Focus length

 60 and 150mm standard Focus length adjustable

Welding Parameter Save

30 kinds of different welding parameter save



Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes: Welding / Cutting / Cleaning 0



Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes : Welding / Cutting / Cleaning Application Advantages:


The HanWei HW - 20 - 60150 Handheld Tri - functional Device showcases outstanding application capabilities. Its remarkable portability is attributed to its sleek and lightweight construction, making it extremely suitable for operations in restricted spaces and mobile work scenarios. This significantly boosts operational agility, doing away with the need for intricate machinery or a large - scale workforce.

This apparatus integrates welding, cutting, and cleaning functions. Regarding the welding aspect, equipped with a 3000W power capacity, it demonstrates remarkable adeptness in fusing steel, stainless steel, and aluminum. The weld width, which is adjustable within the 0 - 5mm range, is capable of satisfying diverse welding demands. When it comes to the cutting function, the laser beam can precisely cut through materials with adjustable cutting velocity and depth. As for the cleaning function, with a 2000W power output, the 0 - 50mm adjustable beam proves highly efficient in cleaning a wide array of surfaces and is applicable in automotive, household, and industrial equipment cleaning.

It is both energy - saving and cost - effective. The single - motor configuration conserves energy, simplifies work procedures, and cuts down on both time and energy consumption. Its uncomplicated structure leads to reduced manufacturing and maintenance costs. Additionally, it is user - oriented, as it doesn't necessitate specialized training, is accessible to a wide spectrum of users, and helps to minimize errors and training - related expenditures.




Powerful Handheld 3-in-1 Laser Welding Machine with 3 Modes : Welding / Cutting / Cleaning Packing:


  • One Handheld Laser Head
  • A set of Connection Cables and Line
  • Seven kinds of nozzles
  • One 15v Power Supply
  • One Touch Screen Monitor
  • One Safety Switch Clip
  • One Controller
  • One Focus Lens for cleaning
  • One Wire feeding device
  • Two Protective Lens
  • One User Manual





Shen Zhen HanWei Laser Enterprise and Feature:



Shenzhen Hanwei Laser Equipment Co., Ltd. is wholeheartedly committed to equipping all global integrators with outstanding welding capabilities. As a newly - recognized national high - tech enterprise, it focuses on the comprehensive industrial chain covering welding lasers, laser control systems, laser optical systems, and laser welding techniques. It undertakes comprehensive research, development, manufacturing, and sales activities. Its product lineup includes nine major series of laser welding equipment. Among them, the AMB Spot Ring Spot Welding Machine, the Blue Light Welding Machine, and their respective accessories stand out.

Hanwei Laser adheres to the business tenet of “prioritizing R & D, backed by technology, and guaranteed by service” to serve B - end customers. It has a professional team with profound expertise and rich experience in the laser welding domain and related fields. The company's products are extensively utilized in multiple industries, such as new - energy batteries, automobiles, electronics, and home appliances, showcasing distinctive welding capabilities. Significantly, the enterprise has attained remarkable technological accomplishments. The AMB Spot Ring Spot + Blue Light Composite Swing Welding Machine is a globally advanced innovation, surmounting the challenges in welding highly reflective materials. Likewise, other models like the AMB Spot Ring Spot + Semiconductor Composite Welding Machine and the Semiconductor + Single Lamp Single Rod 600W Composite Laser Welding Machine have also successfully resolved specific welding issues in the power battery field.
