Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning

Basic Properties
Place of Origin: Shenzhen. China
Brand Name: HanWei
Certification: CE
Model Number: HW-20-60150
Trading Properties
Minimum Order Quantity: 1 Set
Price: USD / Set
Payment Terms: T/T
Supply Ability: 2000 Sets / year
Tags

Stainless Steel Laser Welding Machine

3-in-1 Laser Welding Machine

Aluminium Alloy Laser Welding Machine
Specifications
Handheld Laser Gun Weight: 0.7 Kg Handheld Laser Gun Materials: Aluminium Alloy & Stainless Steel
Welding Materials: Steel / Stainless Steel / Aluminium Laser Power: Up To 3000W For Welding And 2000W For Cleaning
Welding Laser Beam Size: 0-5mm Adjustable Cleaning Laser Beam Size: 0-50mm Adjustable
Welding parameter storage: 30 Kinds Of Different Welding Parameter Save Wire Feeding Device: Standard Type : 0.8&1.0&1.2&1.6mm Wire
Double Route Wire Feeder: Option ( Same Time Double Route Feeding )
High Light:

Handheld Single Motor Cutting Machine

,

Handheld Single Motor Cleaning Machine

,

Handheld Single Motor Welding Machine
Product Description

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor





Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Description:



The Handheld Single Motor 3-in-1 Device emerges as a remarkable innovation in the portable multi-purpose tool landscape. Driven by a solitary yet potent motor, this compact apparatus brings together the prowess of welding, the precision of cutting, and the thoroughness of cleansing, all encased within an ergonomically designed and sleek handheld casing.

In the welding domain, it astutely manages the electrical current and voltage to create a stable and reliable arc, thereby ensuring robust and exact welds on a variety of steel, stainless steel, and aluminum workpieces. When engaged in the cutting operation, a highly focused and intense beam slices through diverse thicknesses of materials with adjustable speed and depth settings, yielding clean and precise separations. For the cleaning function, it sucks in appropriate cleaning agents or water and transforms them into a powerful, adjustable high-pressure spray via a flexible nozzle, effectively eradicating rust, grease, and other impurities. This handheld three-in-one machine showcases unrivaled adaptability and finds utility in numerous settings such as bustling workshops, expansive construction sites, and demanding industrial maintenance tasks, consistently delivering top-notch performance in each of its welding, cutting, and cleaning capabilities.



Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning 0

Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor  Features:

  • Product Name: Fiber Laser 3-in-1 Machine
  • Handheld Laser Gun Weight: 0.7kg
  • Welding Materials: Steel / Stainless Steel / Aluminum
  • Laser Head Connection: QBH
  • Laser Beam Form: Line “一”
  • Laser Power: Up to 3000W for welding and 2000W for cleaning
  • Welding Laser Beam Size: 0-5mm Adjustable
  • Cleaning Laser Beam Size: 0-50mm Adjustable
  • Standard Focus length: 60 and 150mm standard Focus length adjustable
  • Gas: Argon / Nitrogen
  • Cooling method: Water Cooling



The Handheld Single Motor 3-in-1 Appliance stands out as an outstanding alternative for metalworking, machinery restoration, and surface conditioning in workshops and manufacturing facilities. It employs a peak power of 3000W for welding and 2000W for cleaning, granting it the ability to manage steel, stainless steel, and aluminum substances. The laser emission assumes a linear shape and is connected through QBH, necessitating argon or nitrogen gas. The 0.7 - kilogram handheld laser gadget is equipped with an adjustable standard focal length spanning from 60 to 150mm. Additionally, it offers adjustable laser beam widths for welding and cutting, with the welding beam width adjustable from 0 to 5mm and the cleaning beam width from 0 to 50mm. This machine utilizes a Water Cooling mechanism to ensure efficient heat dispersion during operation, thereby maintaining its stable functionality and prolonging its service life.


Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Technical Parameters:



Product Name

Handheld Single Motor 3-in-1 Machine

Adopt Laser Source

1064~1080nm Fiber laser source

Handheld Laser Gun Weight

0.7 KG

Laser Power

Up to 3000W for welding and 2000W for cleaning

Standard Focus length

60 and 150mm standard Focus length adjustable

Wire Feeding Device

Standard type : 0.8&1.0&1.2&1.6mm wire

Double Route Wire Feeder

Option (Same time double route feeding)

Cleaning Beam Form

Line " 一 "

Fiber Connector

QBH

Welding Laser Beam Size

0-5mm Adjustable

Cleaning Laser Beam Size

0-50mm Adjustable

Welding Parameter Input

Touch Screen Monitor



Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning 1



Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Application Advantages:


The HanWei HW - 20 - 60150 Handheld Single Wobble Tri-functional Machine showcases remarkable application capabilities. Its highly favorable portability stems from its compact and lightweight design, making it ideal for confined spaces and mobile applications. This enhances operational flexibility without the need for complex machinery or a large workforce.

This apparatus combines the functions of welding, cutting, and cleaning. In terms of welding, with a power output of 3000W, it is highly competent in joining steel, stainless steel, and aluminum. The welding beam, adjustable within the range of 0 - 5mm, can meet diverse welding requirements. When it comes to the cutting function, the laser beam is capable of dividing materials with adjustable cutting speed and depth. In the cleaning function, with a power of 2000W, the 0 - 50mm adjustable beam is efficient in purifying a wide variety of surfaces and is applicable in automotive, household, and industrial equipment cleaning.

It is energy-efficient and cost-effective. The single-motor configuration saves energy, streamlines work processes, and reduces both time and energy consumption. Its simple structure leads to reductions in manufacturing and maintenance costs. It is also user-friendly, as it does not require specialized training, is accessible to a broad range of users, and helps to minimize errors and training-related expenses.



Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor Packing:


  • One Touch Screen Monitor
  • One Handheld Laser Head
  • One Controller
  • One 15v Power Supply
  • One Wire feeding device
  • One Focus Lens for cleaning
  • A set of Connection Cables and Line
  • Seven kinds of nozzles
  • Two Protective Lens
  • One Safety Switch Clip
  • One User Manual



Handheld Single Motor 3-in-1 Machine with Touch Screen Monitor for Welding, Cutting and Cleaning 2
