2000W Fiber Handheld Single Motor Three-in-One Machine
Handheld Single Motor Three-in-One Machine Description:
The Handheld Single Motor Three-in-One Machine marks a remarkable advancement in portable multi-purpose apparatus. Powered by a solitary, high-capacity motor, this gadget amalgamates three vital functions: welding, slicing, and purging, all encased within a sleek and user-friendly handheld casing.
During the welding process, it meticulously regulates the electrical current and voltage to produce a steady arc, thereby facilitating firm and precise welds on a variety of steel, stainless steel, and aluminum materials. For slicing tasks, a concentrated high-strength beam penetrates diverse material thicknesses with adjustable velocity and depth, guaranteeing neat and productive cuts. In the purging operation, it sucks in cleansing agents or water and converts them into a potent adjustable high-pressure jet through a flexible-nozzle, effectively eradicating rust, grease, and impurities. This machine is highly adaptable and appropriate for numerous settings like workshops, building sites, and industrial upkeep, delivering excellent performance across all three fundamental functions.
Handheld Single Motor Three-in-One Machine Features:
Product Name: Fiber Laser Three-in-One Machine
Laser Power: 2000W
Handheld Laser Gun Weight: 0.7kg
Welding Laser Beam Size: 0-5mm Adjustable
Cleaning Laser Beam Size: 0-50mm Adjustable
Standard Focus length: 60 & 150mm standard Focus length adjustable
Welding Thickness: 6mm Stainless steel Full Penetration
Welding Parameter Save: 30 kinds of different welding parameter save
The Handheld Single Motor Three-in-One Machine proves to be an ideal choice for metal manufacturing, machinery restoration, and surface treatment in workshops and factories. It harnesses a 2000W laser power with an approximate consumption of 10Kw/h, enabling it to weld steel, stainless steel, and aluminum, and even achieve full penetration on 6mm stainless steel. The laser beam exhibits a linear form and is connected via QBH, with a requirement for argon or nitrogen gas. The 0.7kg handheld laser apparatus is equipped with an adjustable standard focal length spanning from 60 to 150mm. Additionally, it offers adjustable laser beam sizes for welding and cutting, where the welding beam size can be adjusted from 0 to 5mm and the cleaning beam size from 0 to 50mm.
Handheld Single Motor Three-in-One MachineTechnical Parameters:
Product Name
Handheld Single Motor Three-in-One Machine
Laser Power
2000W
Handheld Laser Gun Weight
0.7 KG
Adopt Laser Source
1064~1080nm Fiber laser source
Welding Laser Beam Size
0-5mm Adjustable
Cleaning Laser Beam Size
0-50mm Adjustable
Standard Focus length
60 & 150mm standard Focus length adjustable
Fiber Connector
QBH
Cleaning Beam Form
Line " 一 "
Wire Feeding Device
Standard type : 0.8&1.0&1.2&1.6mm wire
Double Route Wire Feeder
Option (Same time double route feeding)
Welding Parameter Save
30 kinds of different welding parameter save
Handheld Single Motor Three-in-One MachineApplication Advantages:
The HanWei HW - DZJS - 2000 Handheld Single Oscillation Tri-functional Machine exhibits remarkable application superiority. Its highly convenient portability stems from its compact and lightweight configuration, making it apt for confined spaces and on-the-go operations. This augments operational flexibility without the necessity of elaborate equipment or a large workforce.
This device amalgamates welding, cutting, and cleaning capabilities. In the welding function, possessing 2000W of power, it can perform welding on steel, stainless steel, and aluminum, attaining full penetration for 6mm stainless steel. The welding beam, adjustable within the range of 0 - 5mm, can adapt to diverse welding requirements. Regarding the cutting function, the laser beam can slice through materials with adjustable cutting speed and depth. In the cleaning function, the 0 - 50mm adjustable beam is efficacious in cleansing a variety of surfaces and is applicable in automotive, household, and industrial equipment cleaning.
It is energy-conserving and cost-efficient. The single-motor design economizes energy, streamlines work processes, curtails both time and energy consumption. Its uncomplicated structure leads to reductions in manufacturing and maintenance expenditures. It is also user-friendly, as it demands no specialized training, is accessible to a wide range of users, and helps to minimize errors and training-related costs.
Handheld Single Motor Three-in-One Machine Packing:
One Handheld Laser Gun
A set of Connection Cables and Line
One Touch Screen Monitor
One Controller
One Safety Switch Clip
One Focus Lens for cleaning
Two Protective Lens
One 15v Power Supply
Seven kinds of nozzles
One Wire feeding device
One User Manual
