445nm Blue Laser Diode Source High Absorption Laser For Copper And Brass
Description
The blue laser is a device that emits a light beam in the wavelength range between 400 nm and 500 nm, visible as violet or blue to the human eye. The light beam produced is temporally coherent and can be well-collimated, which allows it to have numerous applications in industry and science.
The primary advantage of the blue laser is its high absorption in a variety of materials. Copper absorbs over 10 times more blue light as infrared, and 20 percent more blue than green light. Consider the implications for welding.
Blue light lasers have a shorter wavelength compared to red lasers, allowing for stronger focus or resolution in very fine structures in imaging applications.
The practical applications for blue lasers are many. The telecommunications, information technology, environmental monitoring, medical diagnostics and electronic equipment industries all have benefited from blue light lasers. Micro projectors and displays can use blue lasers for operational purposes.
HANWEI laser has started to research and develop Blue-laser almost at the same time with laser welding enterprise in Europe, America and Japan.Use independent R&D blue laser system to create new laser welding fields (Blue laser source, Blue- laser control system, Many kinds of multiple special purpose of blue welding head).
HW-Blue laser mainly used for copper welding, silver welding, gold welding and other High reflectivity materials welding. The Blue laser with incomparable super high absorptivity (The high reflectivity materials in Blue-laser wave range with more than 60% absorptivity).
Widely used in new energy industry, semiconductor industry.
Advantage
The Blue laser with greatest advantages in High reflectivity materials welding: Welding process with Low spatter, High stability, High welding effect and quality, One-side welding with back side formation advantages.
Specification
| Model | HW-B-50W | HW-B-100W | HW-B-200W | HW-B-500W | HW-B-1000W |
| Laser Power | 50 W | 100 W | 200 W | 500 W | 1000 W |
| Wavelength | 445 nm | 445 nm | 445 nm | 445 nm | 445 nm |
| Output power | 50 W | 100 W | 200 W | 500 W | 1000 W |
| Power stability | ± 0.5 % | ± 0.5 % | ± 0.5 % | ± 0.5 % | ± 0.5 % |
| Cooling way | Air | Water | Water | Water | Water |
| Equipment power | 250 W | 1000 W | 2000 W | 4000 W | 5000 W |
| Pulse width | 0.5~CW | 0.5~CW | 0.5~CW | 0.5~CW | 0.5~CW |
| Welding head Model | HW-36-T-D80 | HW-36-T-QBH |
| Usable Power | 50 - 200 W | ≥500 W Minimum |
| Collimating length | 70 | 70 |
| Focus length | 70 / 150 | 70 / 150 |
| Interface type | D80 | QBH |
| Accessible wave range | 1064 | 1064 |
| Head Type | T | T |
| Net weight | 1.1 kg | 2.5 kg |
| Usable laser source | Blue laser | Blue laser |
We provide technical support and service to customers using our Handheld Welding Head products. Our support staff is available to answer any questions about the product, provide troubleshooting advice, and help with product installation and maintenance. We also offer extended warranties and replacement parts for our Handheld Welding Head products.
If you have any questions or need assistance with our Handheld Welding Head products, please contact us.
HanWei Laser already have been shipped and served lot's of over customers in various countries all of the world. Have dealers and agent in all of the world. Support on line remote technical support in time and local agent technical support.
The Handheld Welding Head is packaged in a paper box ,wooden frame or plywood, secured with packaging foam. The box is then labeled with the product name, size, and shipping address. The product is then shipped through a third-party shipping service.
HanWei Laser already have been shipped and served lot's of over customers in various countries all of the world.
Hanwei Laser Equipment Co.,Ltd is a leading corporation of laser welding systems for a variety of industries, is the worldwide innovation leader in the development of components and system solutions in the field of laser welding technology, including automobile battery, new energy resources, energy storages, aerospace, jewelry, metal processing, medical, plastic, and more.
Hanwei laser Founded in 2016, the company has over two decades of experience in the industry and utilizes the latest technology to provide innovative, reliable, and high-quality laser solutions.
Great changes are driven by technology. And technologies change the world.
The company offers a range of laser systems, including desktop and handheld laser system models, that use advanced fiber, pulsed or continuous wave, blue laser, diode laser, hybrid laser technology to meet the exact needs of their customers. Also provide custom solutions for specialized applications and offer training and support to help their customers get the most out of their laser systems.
Hanwei Laser has a global presence with offices and distributors in Europe, North America, Asia, and Middle East, making it accessible to customers all over the world.
The company has a reputation for excellent customer service, quality products, and innovative solutions, which have made it a trusted name in the laser welding industry.
